Main function:

  • Automatic sliding cover
  • Semiconductor fingerprint sensor
  • Phone management at anytime
  • Prevent open the door from door viewer
  • Anti-peeping password design
  • Smart touch panel
  • 5 unlock ways

Mode: D1s

Color: Phantom Black/Antique copper

Unlock: Fingerprint/card/password/key/Bluetooth

Lock body: S5231 anti-theft lock body

Design: Automatic sliding cover

Way to open the door: Right/Left/Inwards/Outwards

Verification time:≤1s

Verification angle:360°

Static Current: ≤50μA

Dynamic Current: ≤250mA

Data Capacity:300pcs Fingerprint

Finger Reader:Semiconductor Fingerprint sensor

FRR : ≤0.1%

FAR: ≤0.0001%

Card frequency:13.56Mhz

Card compatible type:Mifare-1 s50/s70 compatible card

Working Temperature: -20℃~60℃

Working Humidity: 20%~90%RH

OLED display screen: Standard

Password length: 6 -12 bit

Low voltage alarm:4.8±0.2V

Lock cylinder:Anti-theft lock cylinder

Door type: Wooden door, security door

Induction time: ≤0.5s

Emergency service:5VDC

Battery type: 6VDC

Voice:Human-sounding voice

Key panel: 12 bit touch panel
